MoTeC M142 LAMBORGHINI HURACAN 2014 KIT (Licence)
MoTeC M142 LAMBORGHINI HURACAN 2014 KIT (Licence)
MoTeC SKU 11407
DESCRIPTION:
This Plug-In Kit provides a complete replacement for the factory OE (original equipment) ECUs for the Lamborghini Huracan or Audi R8 engine. Using existing wiring, the original fuel system and sensors, it delivers convenient installation with fully programmable control.
Two M142 ECUs are supplied, one acting as a Master ECU, in which all common tuning adjustments are made, the other as a Slave ECU that takes commands from the Master, together providing full functionality plus Engine Torque Control and additional features unique to these vehicles.
Along with fuel, ignition, throttle and camshaft control, this Kit also supports other OE ECU features, including:
Push button start
7-Speed DSG transmission integration with tunable shift cuts and blips
Direct injector with high pressure fuel pump control, and secondary port injector control.
Optional boost control via wastegate solenoids or servos
Air conditioner control
Variable speed fan control
Map switching from driving modes (Strada, Sport, Corsa) and from cruise control buttons / stalk
Fuel lift pump and coolant pump control
Cruise control
Integrated electronics for OE Lambda sensors
All OE dash functionality including warnings
The Package contains the base calibration and all settings for the sensors, direct fuel injectors, port fuel injectors, ignition coils, knock control, throttle servos and camshafts. They have also been calibrated to match the OE factory fuelling, ignition and camshaft phasing. This saves a significant amount of time by shortcutting the setup process. Users can begin tuning to their desired power level right away with the assurance of a safe base tune that is equivalent to the original vehicle.
Included are many ancillary features commonly found on race cars, such as anti-lag, driver switches (e.g. pit switch, launch enable, boost trim), gearbox control, knock control, intercooler sprays, launch control, coolant pumps and traction control.
The product fully integrates with other MoTeC devices, providing pre-defined CAN messaging for all current Displays/Loggers, LTCs, E888, Video Capture Systems, GPS, ADR, BR2, PDMs and SLMs.
KIT CONTENTS: This Plug-In Kit provides a complete replacement for the factory OE (original equipment) ECUs for the Lamborghini Huracan or Audi R8 engine. Using existing wiring, the original fuel system and sensors, it delivers convenient installation with fully programmable control. Two M142 ECUs are supplied, one acting as a Master ECU, in which all common tuning adjustments are made, the other as a Slave ECU that takes commands from the Master, together providing full functionality plus Engine Torque Control and additional features unique to these vehicles. Along with fuel, ignition, throttle and camshaft control, this Kit also supports other OE ECU features, including:
Hardware
13142 - M142 ECU x 2
61432 - M142 LAMBORGH HURACAN 2014 ADAPTOR KIT
61404 - M1 ADAPTOR 250MM 26W KEY 1 STUB LOOM x 2
61405 - M1 ADAPTOR 250MM 26W KEY 3 STUB LOOM x 2
61406 - M1 ADAPTOR 250MM 34W KEY 1 STUB LOOM x 2
61407 - M1 ADAPTOR 250MM 34W KEY 2 STUB LOOM x 2
61433 - M142 LAMBO HURACAN 2014 BREAKOUT LOOM
61434 - M142 LAMBO HURACAN 2014 ADAPT MASTER BOX
61436 - M142 LAMBO HURACAN 2014 ADAPT SLAVE BOX
Licence
23390 – M1 LIC - LAMBORGHINI HURACAN 2014 MASTER
23391 – M1 LIC - LAMBORGHINI HURACAN 2014 SLAVE
These Licences are required to run the Lamborghini Huracan 2014 Master and Slave M1 Packages in the M142 ECUs.
