This M142 Plug-In ECU Kit provides a complete replacement for the OE (original equipment) ECU for the Toyota Yaris GR. Using existing wiring, the original fuel system and sensors, it delivers convenient installation with fully programmable control.

Using the optional Diff Loom (#61466) the kit provides programmable rear Diff Control that integrates with the Drive Mode Switch.

Along with fuel, ignition, throttle and camshaft control, this Kit also supports other OE ECU features, including:

  • Selectable Drive Mode including Normal, Sport, and Track using OE controls
  • Head-Up Display
  • Direct injector with high pressure fuel pump control and secondary port injector control (saturated high-ohm injectors only)
  • Cruise control
  • OE dash functionality including warnings

** Drivers should be aware that specifically the following standard features do not work utilising this M1 Package:

  • Active Cruise Control
  • Dynamic Stability Control
  • Low Speed Pre-Collision System and Lane Trace Assist
  • Hill Hold Assist




Kit includes:

  • 13142M - M142 ECU MARINE
  • 61608 - M142 TOYOTA YARIS GR 2020 ADAPTOR KIT
    • 61609 - M142 TOYOTA YARIS GR 2020 ADAPTOR BOX
    • 61253 - M1 ADAPTOR 200MM 26W KEY 1 STUB LOOM
    • 61251 - M1 ADAPTOR 120MM 26W KEY 3 STUB LOOM
    • 61252 - M1 ADAPTOR 120MM 34W KEY 1 STUB LOOM
    • 61250 - M1 ADAPTOR 200MM 34W KEY 2 STUB LOOM
    • 57006 - BOSCH LSU 4.9 WIDEBAND LAMBDA SENSOR
    • 61430 - M1 ADAPTOR LTC LOOM
    • 61300K - LTC - LSU LAMBDA TO CAN (500K)
    • 61461 - TOYOTA YARIS GR 2020 GATEWAY LOOM
    • 61610 - M142 YARIS GR 2020 MOUNTING KIT
      • 1 x DTM 2 Pin Male Connector
      • 1 x DTM 2 Pin Female Connector
      • 1 x M3 x 8mm S/S Button Socket Screw
      • 2 x M5 S/S Flat Washer
      • 2 x M5 x 25mm S/S Button Socket Screw
      • Cable Tie Mount
      • 4 x 4.8 x 200mm Cable Ties
Licence

  • 23578 – M1 LICENCE - TOYOTA YARIS GR

This Licence is required to run the M142 TOYOTA YARIS GR 2020 Package in the M142 ECU.

Differential Control:

This Kit provides programmable control of the active rear differential clutch of the Toyota Yaris GR.

Compatible with the OE Yaris 3 position Drive Mode Switch.

Numerous diff modes are configurable within the M1 Package, using MoTeC's 9 Position Switch (#56100).

MoTeC's Toyota Yaris GR 2020 Diff Loom - Click here

For full information about this product, please click here

MoTeC SKU M-11417
